Pelty McPeltface

File this under inevitable, but still funny.

The neighbouring Belgian towns of Neerpelt and Overpelt are to merge and a new name is being sought for the merged municipality.

The final decision as to the new name is in November, at which point we will discover whether or not the local Limburgers will find themselves living in Pelty McPeltface.

Flattr this!

Using regular expressions in DB2 for i

Regular expressions have been supported in DB2 for a while now and, while they are not something I often need, there are times when they come in very handy indeed. A simple example involves cleaning up some data so that it can be exported from an old (poorly maintained) database to a new, shiny one that (I’m promised) absolutely will be used.

The database in question is an employee master and, in order to protect the innocent, I have both simplified it and changed the names for the purpose if this example. There are only two fields to worry about empnumber and empname, which represent the employee number and name respectively. There are a couple of issues to address. The first one is that the empnumber is ten characters in the old database but five numeric in the new, so I need to ensure that all the numbers fit.

The second issue is that this database has been very poorly maintained. If you allow someone to enter a character in a numeric field, they will. And they did.

Here’s an idea of how the database looked:

EMPNUMBER   EMPNAME
00001       Bugs Bunny
OOOO2       Elmer Fudd
0000000003  Daffy Duck
-4          Speedy Gonzales
00005       Sylvester

As you can see, there are lots of ways in which the employee number can be invalid, and these have all been very well explored. And watch out for Elmer Fudd — he’s a bit confused about the difference between letters and numbers.

Fortunately REGEXP_INSTR is your friend:

The REGEXP_INSTR returns the starting position or the position after the end of the matched substring, depending on the value of the return_option argument.

So all I need is a regular expression that identifies which employee numbers are five digits followed by spaces, and which aren’t. And here it is:

select * from employees
where regexp_instr(empnumber, '^\d{5}\s+$') != 1

There are several optional parameters but I only need to use the source string (empnumber) and the pattern expression. The expression I am using looks for digits in the first five characters followed by spaces to the end of the field. And this is the result:

EMPNUMBER   EMPNAME
OOOO2       Elmer Fudd
0000000003  Daffy Duck
-4          Speedy Gonzales

I told you that Elmer Fudd was tricksy.

It should also be possible to use REGEXP_REPLACE to automate some of the cleanup, but you really do need your business users to buy in before you go down that particular rabbit hole.

Flattr this!

Quoridor

One game that was brought out quite frequently over the summer was Quoridor. A large part of this is that, with nice solidly wooden pieces on a nice solid wooden board, there is no risk of anything blowing away while we wait for the barbecue. But the game itself is also very playable indeed.

The rules are simple. The game is played on an 9×9 grid and the object is to get your pawn from one side of the board to the other. On each turn you can either move your pawn or place a wall to hinder your opponent, but not completely block access to the opposite side. And that’s it.

As with the best of abstract games, a very simple set of rules allows for a great deal of depth in the actual play. In the case of Quoridor, the trick is to place walls to ensure that your opponent has to follow the longest path possible while also preventing them from lengthening your path too much (that rule about not completely blocking access to the other side — it can lead to all sorts of mazes).

It’s a quick game to play as well, with each game taking no more than 20 minutes to play. Given that the boys are 7 and 10, this shortness ensures that neither boredom nor frustration have any time to set in. On the downside, it means that we haven’t (yet) needed to explore the four-player version.

But we will.

Flattr this!

Adding variables to ad-hoc SQL queries with CL

Some time ago I mentioned using REXX to build and execute ad-hoc SQL queries. For the sake of completeness, here is the same solution implemented in CL using the RUNSQL command.

The program does exactly the same as the previously describe REXX script — extracts all records flagged with today’s date so that they can be reviewed at a later date. And here it is:

pgm
dcl &date6 *char 6
dcl &date8 *char 8
dcl &statement *char 255

/* First retrieve the current system date (QDATE)                             */
/* and convert it to an 8 character value                                     */
RTVSYSVAL  SYSVAL(QDATE) RTNVAR(&DATE6)
CVTDAT     DATE(&DATE6) TOVAR(&DATE8) FROMFMT(*JOB) TOFMT(*YYMD) TOSEP(*NONE)

/* Next, build the SQL statement                                              */
CHGVAR     VAR(&STATEMENT) +
           VALUE('insert into EXPATPAUL1/INPUTDATA' *bcat +
                 'select * from EXPATPAUL1/PRODDATA where dhdate =' *bcat +
                 &date8)
runsql sql(&statement) commit(*none)

endpgm

Flattr this!

Manhunt

I was quite a fan of John Woo back in the day. Films like The Killer, Bullet in the Head and Hard Boiled were violent in ways I had never seen before and hugely fun to watch.

Time moved on, Woo moved to Hollywood and life got in the way of me keeping up with his more mainstream output. But maybe I should make more of an effort because, according to Peter Bradshaw, Woo is back with a vengeance with his latest film, Manhunt.

Manhunt zooms and crashes along like a stick-shift car, with Woo at the wheel careening between action set pieces, broad comedy, champagne-swilling party scenes, flashbacks and swoony emotional moments. Of course it is a little absurd, and audiences are entitled to ask how Du Qui has not been implicated in Sakai’s drug conspiracy, especially as the bad guy clearly thinks that his lawyer knows enough to require taking out. But this film offers something that is never in sufficiently
plentiful supply: fun.

I shall have to start watching those cinema times again.

Flattr this!

Service Programs and Call Stack APIs

I’m a big fan of service programs. From a maintainability point of view, encapsulated procedures are great. And exported procedures, which mean you only need to develop any piece of functionality once, are even better.

However, I now find myself in the position of having to start creating a set of these from scratch (nothing to copy/paste) and, since they can be a bit fiddly, now seems like a good time to document the steps.

In the example that follows, I create a service program with a single procedure, RtvProgram, which returns the name of the program that called the service program. It sounds a bit recursive, I know, but bear with me. Whenever coding a display file (or a report, for that matter) I like to put the program name somewhere on the screen (top left, unless someone tells me otherwise). This means that when someone has a problem, we can very quickly identify what program they are talking about.

Obviously, hard-coding the program name in the display file would be easy. But code gets copied and pasted and, sooner or later, all hard coded values end up being wrong. I have also seen cases of one display file being used by two or more programs, so it is much better to put the program name in a field and retrieve it dynamically. That way, you are always getting the right program.

So on to the service program.

First, you need a copy member to contain the procedure prototype. You could, of course, code the prototype in each program that uses the service program, but that way madness lies.

In my case, I have created the copy member in QRPGLESRC and called it LSS001RP. It looks like this:

 * Retrieve Program Name
d RtvProgram      pr            10a

And then you need to write the service program:

 * ---------------------------------------------------------------------- *
 * Program     : LSS001R                                                  *
 * Description : Program information service programs                     *
 * ---------------------------------------------------------------------- *
h nomain

 * ---------------------------------------------------------------------- *
 * Exportable Prototypes                                                  *
 * ---------------------------------------------------------------------- *
 /copy LSCLIB/qrpglesrc,lss001rp

 * ---------------------------------------------------------------------- *
 * API Prototypes                                                         *
 * ---------------------------------------------------------------------- *
d RtvCallStack    pr                  extpgm('QWVRCSTK')
d                             2000a
d                               10i 0
d                                8a
d                               56a
d                                8a
d                               15a

 * ---------------------------------------------------------------------- *
 * RtvProgram: Retrieve the program name                                  *
 * ---------------------------------------------------------------------- *
p RtvProgram      b                   export
d RtvProgram      pi            10a

d Var             ds          2000    qualified
d  BytAvl                       10i 0
d  BytRtn                       10i 0
d  Entries                      10i 0
d  Offset                       10i 0
d  Count                        10i 0

d JobID           ds                  qualified
d  QName                        26a   inz('*')
d  IntID                        16a
d  Res3                          2a   inz(*loval)
d  ThreadInd                    10i 0 inz(1)
d  Thread                        8a   inz(*loval)

d Entry           ds                  qualified
d  Length                       10i 0
d  Program                      10a   overlay(Entry: 25)
d  Library                      10a   overlay(Entry: 35)

d VarLength       s             10i 0 inz(%size(Var))
d RcvFormat       s              8a   inz('CSTK0100')
d JobIdFmt        s              8a   inz('JIDF0100')
d ApiError        s             15a
d i               s             10i 0
 /free

     RtvCallStack(Var: VarLength: RcvFormat: JobID: JobIdFmt : ApiError);
     for i = 1 to 2;
         Entry = %subst(Var: Var.Offset + 1);
         Var.Offset += Entry.Length;
     endfor;

     return Entry.Program;

 /end-free
p RtvProgram      e
 * ---------------------------------------------------------------------- *

I’m not going to go into too much detail here. The service program LSS001R contains one procedure, RtvProgram which uses the QWVRCSTK API to retrieve the current call stack then it reads back two entries: The first entry is the service program and the second entry is the calling program. And this is the program name that it returns.

You now need to create the RPG Module. Note the terminology here — you are not creating a Bound RPG Program (it’s the difference between options 15 and 14 in PDM).

I also need the binding source. In this case, the member is called LSS001S and I have put it in the QSRVSRC source file. It looks like this:

STRPGMEXP  PGMLVL(*CURRENT)
    EXPORT SYMBOL('RTVPROGRAM')
ENDPGMEXP

Note that the capitalisation is actually important here.

And now I’m ready to create the service program:

CRTSRVPGM SRVPGM(LSCLIB/LSS001R) MODULE(LSCLIB/LSS001R) SRCFILE(LSCLIB/QSRVSRC) SRCMBR(LSS001S)

Since I’m doing this from scratch, I need to create a binder directory:

CRTBNDDIR BNDDIR(LSCLIB/LSBNDDIR) TEXT('General purpose binding directory')

And add the service program to it:

ADDBNDDIRE BNDDIR(LSCLIB/LSBNDDIR) OBJ((LSS001R))

And we’re ready to go. All I have to do now is make a couple of amendments to the main program to take advantage of the service program:

The control spec needs this line:

h bnddir('LSBNDDIR')

Obviously, I need to copy the prototype definition somewhere in the definition specification:

 /copy LSCLIB/qrpglesrc,lss001rp

And when the program starts, I need to identify the name of the program:

 /free

     // Identify the current program
     program = RtvProgram();


And that’s it.

Flattr this!

Using EXTFILE to override files within RPG

So here’s the situation: Five warehouses populating five sets of files (same filenames, different libraries) and I have an RPGLE program that needs to read through each of these to accumulate dispatch information.

The traditional way of doing this would involve writing a CL program to OVRDBF to each file before calling the RPGLE program. This works, but it’s a bit messy and this can cause future maintenance problems. It’s much better, therefore, to specify the file (and library) to open within the RPGLE program itself. You can do this with the EXTFILE keyword.

Here’s an example:

 * ---------------------------------------------------------------------- *
 * Program     : LSX001R                                                  *
 * Description : Dynamically select which file to open                    *
 * ---------------------------------------------------------------------- *
h main(Main)
fMOVEMENTS if   e           k DISK    usropn extfile(filename)

d Main            pr                  extpgm('LSX001R')
d  library                      10a

dfilename         s             21a

 * ------------------------------------------------------------------------
 * Main Procedure
 * ------------------------------------------------------------------------
p Main            b
d Main            pi
d  library                      10a
 /free

     filename = %trim(library) + '/' + 'MOVEMENTS';
     open MOVEMENTS;

     // Do whatever processing on the file needs to be done...

     close MOVEMENTS;

 /end-free
p Main            e

Hopefully this is reasonably straightforward. In the file spec for the MOVEMENTS file, I have used EXTFILE with a variable filename to specify the actual file opened. I have also used the USROPN keyword as I need to populate the filename variable before I attempt to open the file.

Populating this field is pretty simple. I pass the library name to the program as a parameter and the first thing the Main procedure does is concatenate the library and file with a ‘/’ separator.

Now I can open the correct file, do whatever processing is necessary, and then close the file afterwards.

A similar approach, using the EXTMBR keyword can also be used to open a specific file member. You can, of course, combine EXTFILE and EXTMBR in order to dynamically determine both the file and member, if you really want to.

It should be noted that this will only work if you are using traditional database IO. Any embedded SQL will remain unaffected by anything you do in the F-Spec. If you want to do something similar with SQL, you will need to look into the CREATE ALIAS statement.

Flattr this!
